Running WordPress on containers isn’t the hard part anymore — operating it correctly at the edge is.

This article documents my real-world experience migrating a production WordPress site to Azure Container Apps and then introducing Azure Front Door as a shared edge layer — with zero downtime, managed TLS, and a clean rollback strategy.

No theory. Just what actually worked.

---

Starting Point

• WordPress running in Azure Container Apps
• Public ACA ingress working
• Apex domain only (no www)
• DNS hosted in Azure DNS
• Old Azure App Service still existed as a fallback

At this stage, the site was functional — but directly exposed.

That meant:

• No global edge
• No centralized TLS strategy
• No bot mitigation
• No clean path for future apps

---

Why Add Azure Front Door?

I didn’t add Front Door for performance alone.

I added it because it establishes a clear architectural boundary:

Internet
   ↓
Azure Front Door (edge, TLS, security)
   ↓
Azure Container Apps (origin)
   ↓
WordPress

This separation matters more than people realize.

---

Key Design Decisions (and Why They Matter)

1. Front Door Is a Shared Service

Front Door does not belong to a single app.

It lives in a shared resource group because:

• It will front multiple apps later
• It owns certificates and security posture
• It changes less frequently than workloads

This single decision avoids future rework.

---

2. No Downtime DNS Strategy

The order of operations was critical:

1. Create Front Door without touching DNS
2. Wire Front Door → ACA using the containerapps.io hostname
3. Test via *.azurefd.net
4. Add custom domain to Front Door
5. Validate domain using TXT record (safe)
6. Only then switch DNS using an Alias A record

Rollback was instant:

• Delete Alias
• Restore old A record

No drama.

---

3. Managed TLS Everywhere

Both ACA and Front Door used managed certificates.

No Key Vault.
No renewals.
No cron jobs.

TLS became an implementation detail — exactly how it should be.

---

4. ACA Ingress Lockdown (Reality Check)

The plan was to lock ACA ingress to Front Door only.

Reality:

• Azure Container Apps does not support Front Door service tags
• Static IP allowlists are fragile
• Header-based enforcement isn’t first-class yet

Decision:
Leave ACA ingress open temporarily, and enforce security at the edge.

This wasn’t a failure — it was an informed architectural decision.

---

Bot Protection: What Actually Works on Front Door Standard

One important lesson:

Managed OWASP & Bot rule sets now require Front Door Premium.

On Standard, real protection comes from:

• Rate limiting
• Endpoint-specific throttling
• Edge enforcement (before ACA ever sees traffic)

What I implemented

• Global per-IP rate limiting
• Aggressive limits on /wp-login.php
• Optional limits on /xmlrpc.php

This stopped:

• Brute-force attempts
• Credential stuffing
• Scrapers

For a WordPress blog, this covered 90% of real-world abuse at a fraction of the cost.

---

RBAC & Governance Lessons

Another surprise (but an important one):

• Global Admin ≠ Azure Resource Owner
• Contributor cannot manage resource locks
• Locks require Owner or User Access Administrator

Azure intentionally separates:

• Identity authority (Entra ID)
• Resource authority (Azure RBAC)

It’s inconvenient — but correct.

Final Architecture

Final state:

• Azure Front Door as shared edge
• WordPress on Azure Container Apps
• Managed TLS end-to-end
• Rate-limited bot protection
• Clean DNS alias cutover
• Old App Service safely retired

---

What I’d Do the Same Again

• Treat Front Door as a platform capability
• Test everything before DNS changes
• Prefer managed services over custom plumbing
• Accept platform limits early instead of fighting them

---

What I’d Change Next Time

• Plan WAF tier selection earlier (Standard vs Premium)
• Document RBAC needs upfront
• Automate rate-limit rules via IaC sooner

---

Final Takeaway

Containers are easy. Edges are where architecture shows.

Using Azure Front Door in front of Azure Container Apps gave me:

• A clean security boundary
• A future-proof edge
• Zero-downtime migration
• Operational simplicity

This setup scales from a personal blog to multi-app platforms without changing the fundamentals — and that’s the real win.
